Combo Metal Detector and Checkweigher
Metal detector and checkweigher combo machine, metal detection and weight check can become one at the same time with the use of this machine . Widely used for food, agricultural products, medicine, consumable and other industries. There is only one frame that connects perfectly both the metal detector and chechweigher, for easy and efficient installation. This complex machine has a compact design and offers space savings and installation costs.
The Metal detector and checkweigher combo machine can be combined with the Automatic Traysealer TRAVE and fillers of G.Mondini. You can also combine the Techik weight controller with other control and weighing systems.
Pms Hellas has long experience in the field of food industry equipment. It can offer packaging and processing machines as well as packaging consumables. It also offers personalized solutions for all production units, small – medium – large capacity.
PMS HELLAS offers comprehensive technical support (training-spare parts-maintenance) as it knows very well what industrial production means. It has a technical department staffed by specialized technicians who offer their services all days of the week.
We will be happy to respond to your request and together we will design the best solution according to your needs.
For more information you can go to the site of Techik.
Advantages:
1.Compact design, saving space and installation cost
2.Metal detector and checkweigher is perfectly connected in one frame, to install the machine in workshop conveniently and effectively
Specifications
| Model | IMC-230L | IMC-300 | |
| Detecting Range | 20~2000g | 20~5000g | |
| Scale Interval | 0.1g | 0.2g | |
| Accuracy(3σ) | ±0.2g | ±0.5g | |
| Detecting Speed (Max Speed) | 155pcs/min | 140pcs/min | |
| Maximum Belt Speed | 70m/min | 70m/min | |
| Weighed Product Size | Width | 220mm | 290mm |
| Length | 350mm | 400mm | |
| Height | 70mm, 110mm, 140mm, 170mm | ||
| Weighed Platform Size | Width | 230mm | 300mm |
| Length | 450mm | 500mm | |
| Height | 80mm, 120mm, 150mm, 180mm | ||
| Sensitivity | Fe | Φ0.5mm, Φ0.7mm, Φ0.7mm, Φ0.7mm | |
| SUS | Φ1.2mm, Φ1.5mm, Φ1.5mm, Φ2.0mm | ||
| Product Storage Quantity | 100 kinds | ||
| Segments Number of Sorting | 3 | ||
| Rejecter | Rejecter optional | ||
| Power Supply | AC220V（Optional） | ||
| Degree of Protection | IP54/IP66 | ||
| Main Material | Mirror Polished/Sand blasted | ||
*Note:
1.The technical parameter above namely is the result of accuracy by checking only the test sample on the belt. The accuracy would be affected according to the detecting speed and product weight.
2.The detecting speed above will be affected according to the product size to be checked.
3.Requirements for different sizes by customers can be fulfilled.
